Taps & Dies

Alpha HSS-E Tap UNF Spiral Point 3/8x24

FEATURES:- Premium grade HSS-E raw material- Manufactured to ISO and DIN StandardsSPECIFICATIONS:- Diameter: 3/8"- TPI: 24 tpi- Overall Length: 80 mm- Drill Size: 8.5- Style: Fine - Spiral Point- Measure Standard: UNF

Alpha M20 2.5P MC HSS-E Spiral Flute Tap

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 20- Drill Size (mm): 17- Flute Length (mm): 30- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 140- Pitch (mm): 2.5- Shank Size (mm): 16- Longest side (mm): 140...

Alpha Spiral Flute Tap 18x2.5

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 18- Drill Size (mm): 15.5- Flute Length (mm): 30- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 125- Pitch (mm): 2.5- Shank Size (mm): 14- Longest side (mm): 130...

Alpha Spiral Flute Tap 14x2

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 14- Drill Size (mm): 12- Flute Length (mm): 25- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 110- Pitch (mm): 2- Shank Size (mm): 11- Longest side (mm): 110.00-...

Alpha Spiral Flute Tap 12x1.75

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 12- Drill Size (mm): 10.2- Flute Length (mm): 23- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 110- Pitch (mm): 1.75- Shank Size (mm): 9- Longest side (mm): 120...

Alpha Spiral Flute Tap 10x1.5

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 10- Drill Size (mm): 8.5- Flute Length (mm): 20- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 100- Pitch (mm): 1.5- Shank Size (mm): 10- Longest side (mm): 115...

Alpha Spiral Flute Tap 8x1.25

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 8- Drill Size (mm): 6.8- Flute Length (mm): 18- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 90- Pitch (mm): 1.25- Shank Size (mm): 8- Longest side (mm): 115...

Alpha Spiral Flute Tap 6x1

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 6- Drill Size (mm): 5- Flute Length (mm): 15- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 80- Pitch (mm): 1- Shank Size (mm): 6- Longest side (mm): 95.00-...

Alpha 1/8 28tpi BSPT HSS Bottoming Tap

SPECIFICATIONS:- Diameter (in): 1/8- Drill Size (mm): 8.4- OAL (mm): 59- TPI: 28- Longest side (mm): 70.00- Median side (mm): 18.00- Shortest side (mm): 18.00- Weight (gr): 25.00

Alpha HSS-E Tap MC Spiral Point-20X2.5

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 20- Drill Size (mm): 17- Flute Length (mm): 25- Head Type: Spiral Point- Material: HSSE- OAL (mm): 140- Pitch (mm): 2.5- Shank Size (mm): 16- Longest side (mm): 140...

Alpha HSS-E Tap MC Spiral Point-18X2.5

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 18- Drill Size (mm): 15.5- Flute Length (mm): 25- Head Type: Spiral Point- Material: HSSE- OAL (mm): 125- Pitch (mm): 2.5- Shank Size (mm): 14- Longest side (mm): 130...

Alpha HSS-E Tap MC Spiral Point-14X2

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 14- Drill Size (mm): 12- Flute Length (mm): 20- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 110- Pitch (mm): 2- Shank Size (mm): 11- Longest side (mm): 115.00-...

Alpha HSS-E Tap MC Spiral Point-8x1.25

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 8- Drill Size (mm): 6.8- Flute Length (mm): 13- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 90- Pitch (mm): 1.25- Shank Size (mm): 8- Longest side (mm): 115...

Alpha Carbon Tap BSF Taper-1/2x16

FEATURES:- BSW / BSF - Carbon - ISO 529- Cut and renew internal threads to exacting standards

Alpha Carbon Tap BSF Intermediate-1/2x16

FEATURES:- BSW / BSF - Carbon - ISO 529- Cut and renew internal threads to exacting standards

Alpha Carbon Tap BSF Bottoming-1/2x16

FEATURES:- BSW / BSF - Carbon - ISO 529- Cut and renew internal threads to exacting standards

Alpha Carbon Die Nut BSF-1/2 x 16

FEATURES:- BSW / BSF - Carbon - ISO 529- Cut and renew external threads to exacting standards

Alpha Carbon Tap Set BSW-1/2x12

FEATURES:- BSW / BSF - Carbon - ISO 529- Cut and renew internal threads to exacting standards

Alpha Carbon Tap Set UNC 3/4 10tpi

FEATURES:- Alpha Carbon Hand Taps are precision manufactured in Europe to ISO529 standards.- Carbon Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Alpha Carbon Tap Set BSPF - 1/4x19 included Taper, Intermediate & Bottoming taps

FEATURES:- UNF / BSPF / NPSF - ISO 529 / ANSI B94-9- Cut and renew external threads to exacting standards

Alpha 1/2 13tpi HSS UNC Tap Set 3pce

FEATURES:- Alpha HSS Hand Taps are precision manufactured in Europe to ISO529 standards.- HSS Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Tap Handle No. 8 M20-M38 3/4-1 1/2 in

SPECIFICATIONS:- Longest side (mm): 550.00- Median side (mm): 65.00- Shortest side (mm): 65.00- Weight (gr): 4645.00

Alpha #6 (17.05mm)Screw Extractor Cobalt Series Carded

FEATURES:- Reverse Tapered Cutting Screw Thread- Square Head for use with Tapping Handles- 6 Common sizes availableTechnical data: - Suits pilot drill: 10.32mm, 13/32" - Suits bold thread diameter: 20.0 &emdash; 27.0mm,51/64 - 1 5/64"

Alpha Carbon Button Die 3/16x1” OD

FEATURES:- High Carbon Steel- Precision manufactured to ISO 529 standards- Cut and renew external threads to exacting standards- Use with 1 button die wrench

Carbon Tap Set MF-12x1.5

FEATURES:- Alpha Carbon Hand Taps are precision manufactured in Europe to ISO529 standards.- Carbon Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Alpha 1/2 13tpi UNC HSS Bottoming Tap

FEATURES:- Alpha HSS Hand Taps are precision manufactured in Europe to ISO529 standards.- HSS Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Alpha 1/2 13tpi UNC HSS Taper Tap

FEATURES:- Alpha HSS Hand Taps are precision manufactured in Europe to ISO529 standards.- HSS Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Alpha 3/8 16tpi UNC HSS Taper Tap

FEATURES:- Alpha HSS Hand Taps are precision manufactured in Europe to ISO529 standards.- HSS Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Alpha M12 1.25P SP HSS Bottoming Tap

FEATURES:- Alpha HSS Hand Taps are precision manufactured in Europe to ISO529 standards.- HSS Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Alpha M12 1.25P SP HSS Taper Tap

FEATURES:- Alpha HSS Hand Taps are precision manufactured in Europe to ISO529 standards.- HSS Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Alpha M10 1.5P MC HSS Bottoming Tap

FEATURES:- Alpha HSS Hand Taps are precision manufactured in Europe to ISO529 standards.- HSS Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Alpha M10 1.5P MC HSS Taper Tap

FEATURES:- Alpha HSS Hand Taps are precision manufactured in Europe to ISO529 standards.- HSS Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...
