Taps & Dies

Alpha 6G 32tpi UNC Carbon Taper Tap

TAPER taps have a lead of eight threads and are used as a starting tap in difficult or high precision holes. Alpha Taper taps can be identified by the single ring on the shaft near the driving square.FEATURES:- Alpha Carbon Hand Taps are precision...

Alpha HSS-E Tap MC Spiral Point-4x0.7

FEATURES:- Metric Coarse Spiral Point/Spiral Flute - HSSE- DIN 371SPECIFICATIONS:- Diameter: 4 mm- Pitch: 0.7 mm- Overall length: 63 mm- Drill Size: 3.3 mm

Alpha HSS-E Tap MC Spiral Point-3x0.5

FEATURES:- Metric Coarse Spiral Point/Spiral Flute - HSSE- DIN 371SPECIFICATIONS:- Diameter: 3 mm- Pitch: 0.5 mm- Overall length: 56 mm- Drill Size: 2.5 mm

Alpha HSS-E Tap MF Spiral Point 10x1.25

FEATURES:- Premium grade HSS-E raw material- Manufactured to ISO and DIN StandardsSPECIFICATIONS:- Diameter: 10 mm- Pitch: 1.25 mm- Overall Length: 100 mm- Drill Size: 8.8- Style: Fine - Spiral Point

Alpha HSS-E Tap UNF Spiral Pt-5/8x18

FEATURES:- Premium grade HSS-E raw material- Manufactured to ISO and DIN StandardsSPECIFICATIONS:- Measure Standard:  UNF Fine- Overall Length:  102 mm- Style:  Spiral Flute- TPI (Teeth per inch):  18- Diameter (inches):  5/8- Drill Size (mm):  14.5

Alpha HSS-E Tap UNF Spiral Pt-1/2x20

FEATURES:- Premium grade HSS-E raw material- Manufactured to ISO and DIN StandardsSPECIFICATIONS:- Diameter: 1/2"- TPI: 20 tpi- Overall Length: 89 mm- Drill Size: 11.5- Style: Fine - Spiral Point- Measure Standard: UNF

Alpha 7/8 9tpi UNC Carbon Bottoming Tap

FEATURES:- Alpha Carbon Hand Taps are precision manufactured in Europe to ISO529 standards.- Carbon Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Alpha M6 1.00P MC HSS Bottoming Tap

FEATURES:- Metric Coarse Spiral Point/Spiral Flute - HSSE- DIN 371SPECIFICATIONS:- Diameter: 6 mm- Pitch: 1 mm- Overall length: 50 mm- Shaft Diameter: 6mm- Drive Square: 4.9mm- Tapping Drill Size: 5 mm

Alpha M30 3.5P MC Carbon Bottoming Tap

FEATURES:- UNF - Carbon - ISO 529- Style - Coarse- Cut and renew external threads to exacting standardsSPECIFICATIONS:- Size: 1"- Size & Thread Pitch: 1" x 12 TPI UNF- Thread Pitch: 12 TPI- Thread Direction: Right Hand- Thread Type: UNF - Fine-...

Alpha Carbon Tap Set UNC 5/8 11tpi

Alpha Tap Sets contain a Taper, Inter and Bottoming tap. TAPER taps have a lead of eight threads and are used as a starting tap in difficult or high precision holes. Alpha Taper taps can be identified by the single ring on the shaft near the driving...

Alpha HSS-E Tap UNF Spiral Point 9/16x18

FEATURES:- Premium grade HSS-E raw material- Manufactured to ISO and DIN StandardsSPECIFICATIONS:- Measure Standard:  UNF Fine- Overall Length:  95 mm- Style:  Spiral Flute- TPI (Teeth per inch):  18- Diameter (inches):  9/16- Drill Size (mm):  19.9

Alpha Carbon Tap Conduit Bottoming - 32x1.5

FEATURES:- Alpha Carbon Hand Taps are precision manufactured in Europe to ISO529 standards.- Carbon Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Alpha Carbon Tap Conduit Taper - 32x1.5

FEATURES:- Alpha Carbon Hand Taps are precision manufactured in Europe to ISO529 standards.- Carbon Hand Taps are general purpose taps suitable for hand and machine operation, and are suitable for production use.- 2N Tolerance for optimum thread fit that...

Alpha HSS Tap NPT Bottoming 1” 11.5tpi

FEATURES:- NPT - ISO 2284 / ANSI B94-9- Style - Pipe TaperSPECIFICATIONS:- Thread Diameter: 1"- TPI: 11.5- Overall Length: 95 mm- Drill Size: 29.0 mm

Alpha HSS-E Tap UNF Spiral Pt-5/16x24

FEATURES:- Premium grade HSS-E raw material- Manufactured to ISO and DIN StandardsSPECIFICATIONS:- Diameter: 5/16"- TPI: 24 tpi- Overall Length: 72 mm- Drill Size: 6.9- Style: Fine - Spiral Point- Measure Standard: UNF

Alpha HSS-E Tap UNF Spiral Pt-1/4x28

FEATURES:- Premium grade HSS-E raw material- Manufactured to ISO and DIN StandardsSPECIFICATIONS:- Diameter: 1/4"- TPI: 28 tpi- Overall Length: 66 mm- Drill Size: 5.5- Style: Fine - Spiral Point- Measure Standard: UNF

Alpha Carbon Tap Set BSW 5/8X11

FEATURES:- BSW / BSF - Carbon - ISO 529- Cut and renew internal threads to exacting standardsSPECIFICATIONS:- Thread Dia: 5/8"- TPI: 11- Overall Length: 102 mm- Drill Size: 13.5 mm

Alpha HSS-E Tap UNF Spiral Point 3/8x24

FEATURES:- Premium grade HSS-E raw material- Manufactured to ISO and DIN StandardsSPECIFICATIONS:- Diameter: 3/8"- TPI: 24 tpi- Overall Length: 80 mm- Drill Size: 8.5- Style: Fine - Spiral Point- Measure Standard: UNF

Alpha M20 2.5P MC HSS-E Spiral Flute Tap

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 20- Drill Size (mm): 17- Flute Length (mm): 30- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 140- Pitch (mm): 2.5- Shank Size (mm): 16- Longest side (mm): 140...

Alpha Spiral Flute Tap 18x2.5

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 18- Drill Size (mm): 15.5- Flute Length (mm): 30- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 125- Pitch (mm): 2.5- Shank Size (mm): 14- Longest side (mm): 130...

Alpha Spiral Flute Tap 14x2

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 14- Drill Size (mm): 12- Flute Length (mm): 25- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 110- Pitch (mm): 2- Shank Size (mm): 11- Longest side (mm): 110.00-...

Alpha Spiral Flute Tap 12x1.75

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 12- Drill Size (mm): 10.2- Flute Length (mm): 23- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 110- Pitch (mm): 1.75- Shank Size (mm): 9- Longest side (mm): 120...

Alpha Spiral Flute Tap 10x1.5

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 10- Drill Size (mm): 8.5- Flute Length (mm): 20- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 100- Pitch (mm): 1.5- Shank Size (mm): 10- Longest side (mm): 115...

Alpha Spiral Flute Tap 8x1.25

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 8- Drill Size (mm): 6.8- Flute Length (mm): 18- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 90- Pitch (mm): 1.25- Shank Size (mm): 8- Longest side (mm): 115...

Alpha Spiral Flute Tap 6x1

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 6- Drill Size (mm): 5- Flute Length (mm): 15- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 80- Pitch (mm): 1- Shank Size (mm): 6- Longest side (mm): 95.00-...

Alpha 1/8 28tpi BSPT HSS Bottoming Tap

SPECIFICATIONS:- Diameter (in): 1/8- Drill Size (mm): 8.4- OAL (mm): 59- TPI: 28- Longest side (mm): 70.00- Median side (mm): 18.00- Shortest side (mm): 18.00- Weight (gr): 25.00

Alpha HSS-E Tap MC Spiral Point-20X2.5

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 20- Drill Size (mm): 17- Flute Length (mm): 25- Head Type: Spiral Point- Material: HSSE- OAL (mm): 140- Pitch (mm): 2.5- Shank Size (mm): 16- Longest side (mm): 140...

Alpha HSS-E Tap MC Spiral Point-18X2.5

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 18- Drill Size (mm): 15.5- Flute Length (mm): 25- Head Type: Spiral Point- Material: HSSE- OAL (mm): 125- Pitch (mm): 2.5- Shank Size (mm): 14- Longest side (mm): 130...

Alpha HSS-E Tap MC Spiral Point-14X2

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 14- Drill Size (mm): 12- Flute Length (mm): 20- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 110- Pitch (mm): 2- Shank Size (mm): 11- Longest side (mm): 115.00-...

Alpha HSS-E Tap MC Spiral Point-8x1.25

Metric Coarse Spiral Point/Spiral Flute - HSSE - DIN 371SPECIFICATIONS:- Diameter (mm): 8- Drill Size (mm): 6.8- Flute Length (mm): 13- Head Type: Spiral Flute- Material: HSSE- OAL (mm): 90- Pitch (mm): 1.25- Shank Size (mm): 8- Longest side (mm): 115...

Alpha Carbon Tap BSF Taper-1/2x16

FEATURES:- BSW / BSF - Carbon - ISO 529- Cut and renew internal threads to exacting standards

Alpha Carbon Tap BSF Intermediate-1/2x16

FEATURES:- BSW / BSF - Carbon - ISO 529- Cut and renew internal threads to exacting standards
