FEATURES:
- HD Backlit Interface
- Synergic MIG Control
- Digital Control MIG Torch
- Push-Pull Gun Ready
- Spool Gun Ready
- Gas & Gasless MIG
- 4 Geared Wire Drive
- Multi-process Welding
- Foot Control Ready
- Trigger Controlled DC Lift Arc TIG
- Advanced MMA Features
- Optional Remote Control
- Smart Fan
TECHNICAL DATA:
- Primary Input Voltage: 240V Single Phase
- Supply Plug: 15 AMP
- Ieff (A): 15
- Rated Output: 30A/15.5V - 250A/26.5V
- No Load Voltage (V): 65
- Protection Class: IP23S
- Insulation Class: H
- Minimum Generator (kVA): 11.0
- Dinse Connectors: 35/50
- Standard: AS/NZ60974-1
- Warranty (Years): 5
- Dimensions (mm): 900×480×760 mm
- Weight (kg): 41.3kg
MIG SPECIFICATIONS:
- MIG Welding Current Range: 30-250A
- MIG Duty Cycle @ 40°C:
- 20% @ 250A
- 60% @ 144A
- 100% @ 112A
- MIG Welding Thickness Range: 1-12mm
TIG SPECIFICATIONS:
- TIG Function Type: DC Lift Arc
- TIG Welding Current Range: 5-250A
- TIG Duty Cycle @ 40°C:
;- 20% @ 250A
;- 60% @ 144A
;- 100% @ 112A
- TIG Welding Thickness: Range 1-10mm
STICK SPECIFICATIONS:
- STICK Welding Current Range: 20-220A
- STICK Duty Cycle @ 40°C:
;- 20% @ 220A
;- 60% @ 127A
;- 100% @ 98A
- STICK Welding Thickness Range: 2-12mm
