The Flextec 650 is a powerful multi-process welder designed to handle all processes. Easy to use and portable to move around a construction or mine sites.
The Flextec 650X expands upon the well-established and proven Flextec 650 platform. Like its predecessor the Flextec 650X is rated at 650 amps, 44 volts at 100 percent duty cycle. It delivers up to 815 amps for heavy applications or a stable arc at low currents for MIG or TIG welding on thin materials.
Features
Use with a wide range of available 3 phase input power
Easy one-knob process selection
Fast arc response means smooth arc action and consistent bead appearance
User weld schedule memory storage allows easy recall of your critical or often repeated weld procedures with applicable feeders (User weld schedule memory settings available only with Power Feed® and Flex Feed® 84 wire feeders)
Synergic one knob control over wire feed speed and voltage with applicable feeders (Synergic control available onlywith Power Feed wire feeders)
Specifications
Input power: 380/460/575/3/50/60
Rated Output: 750A/44V/60% 650A/44V/100%
Input Current: 61/50/4057/47/38
Output Range: 10-815A
Dimensions (mm): 554H x 410W x 745D
Weight (kg): 74.84
The Flextec 650X expands upon the well-established and proven Flextec 650 platform. Like its predecessor the Flextec 650X is rated at 650 amps, 44 volts at 100 percent duty cycle. It delivers up to 815 amps for heavy applications or a stable arc at low currents for MIG or TIG welding on thin materials.
Features
Use with a wide range of available 3 phase input power
Easy one-knob process selection
Fast arc response means smooth arc action and consistent bead appearance
User weld schedule memory storage allows easy recall of your critical or often repeated weld procedures with applicable feeders (User weld schedule memory settings available only with Power Feed® and Flex Feed® 84 wire feeders)
Synergic one knob control over wire feed speed and voltage with applicable feeders (Synergic control available onlywith Power Feed wire feeders)
Specifications
Input power: 380/460/575/3/50/60
Rated Output: 750A/44V/60% 650A/44V/100%
Input Current: 61/50/4057/47/38
Output Range: 10-815A
Dimensions (mm): 554H x 410W x 745D
Weight (kg): 74.84
