Weldclass Force 255MST Mig/Stick/Tig Welder

Functions
- MIG (Gas / Gasless)
- Stick / MMA
- TIG (Lift-Arc)

Features
- 250A max MIG output @ 35% duty cycle
- Weld up to 12mm Mild Steel (max MIG capacity)
- Fitted with 15A** 240V plug
- Power Factor Correction (PFC) - reduced power draw, increased duty-cycle, ideal for long leads & generators
- Manual or Synergic (enter material type & thickness and machine will set parameters automatically)
- 20+ Pre-set Programs - for different materials
- Job Save - store custom settings for up to 20 jobs
- Geared 4-Roll Wire Drive System - for super reliable wirefeeding
- Takes 5kg (D200mm) or 15kg (D300mm)spools
- Spool Gun Ready
- Generator Compatible - min 13kva, ideal 15+kva
- Fan-on-Demand - reduces dust intake
- Stressed-Tested - to 440V & over-specified componentry for reliability
- 3 year warranty*
- Robust & Portable, weighs 26kg

Includes
- MIG Torch 4m BZL 25
- Earth Lead H/Duty 4m
- Stick Lead H/Duty 4m
- Gas Regulator
- Driver Roller for 0.6/0.8mm steel/solid wire
- Driver Roller for 0.9/1.2mm steel/solid wire
- Driver Roller for 0.8/0.9mm gasless wire
- Driver Roller for 1.0/1.2mm aluminium wire
- Cable Retaining Strap
- Long Power Input Lead 3m

Optional
- Spool Gun BZL 25 8m (part no WC-06203)
- TIG Torch #17 4m with Remote Control (part no WC-06234)
- T100 Welding Trolley (part no WC-06235)

*Standard warranty 2 years, with 1 year extension if registered at Weldclass.com.au/WeldforceWarranty
**15 Amp plug fitted for commissioning purposes only. To obtain full output, 25A or 32A plug &; 4.0mm input cable should be installed by the user.
