The RAZOR ARC 140 is the perfect STICK and TIG welder for the professional welder wanting a powerful machine with a portable body. Fitted with a 10 AMP plug, this machine is designed to be taken between the workshop and worksites with ease. Connecting a 17V TIG Torch provides DC Lift Arc TIG functionality. It also features Hot Start, Anti-Stick, and Arc Force capabilities, enhancing its performance and making it an even more versatile tool for welding professionals.
INCLUDES:
- RAZOR ARC 140 Welder
- 4m Twist Lock Electrode Holder
- 4m 300 Amp Earth Clamp & Lead
- Operating Manual
SPECIFICATIONS:
- Primary Input Voltage: 240V Single Phase
- Supply Plug: 10 Amp
- Ieff (A): 9.7
- Rated Output: 20A/20.8V - 140a/25.6V
- No Load Voltage (V): 78
- Protection Class: Ip23s
- Insulation Class: H
- Minimum Generator (KVA): 8
- Dinse Connector: 35/50
- Standard: AS/NZ60974-1
- Welds: MMA: Mild Steel, Stainless Steel, Cast Iron
- Tig: Mild Steel, Stainless Steel, Copper, Silicon Bronze
- Tig Function Type: DC Lift Arc
- Tig Welding Current Range: 10-140A
- Tig Duty Cycle @ 40°C: 20% @ 140A
- 60% @ 80.8A
- 100% @ 62.6A
- Tig Welding Thickness Range: 1-5mm
- Stick Welding Current Range: 20-140A
- Stick Duty Cycle @ 40°C: 15% @ 140A
- 60% @ 70A
- 100% @ 54A
- Stick Electrode Range: 2.5-3.2mm
- Stick Welding Thickness Range: 2-8mm
