Outstanding welding performance is no overstatement. Every element of Minarc Evo 180 is designed to meet the needs of professional welders on the move. Where size, weight and welding quality are concerned, there is no equal.
Ideal for site use, you can use Minarc Evo 180 from mains or generator power supplies, even with extra long supply cables. Minarc Evo is easy to carry, so you can normally take everything you need in one journey.
Package includes earth return and welding cables (3 m) and shoulder strap.
Benefits
- Premium welding performance
- Use with all electrode types
- Use with long supply cables
- PFC technology for ultimate energy efficiency
- High current output and duty cycle
- Lightweight and portable
- Robust and durable
- Precise lift TIG technology
- Mains network or generator use
- Optional remote control
- Kemppi 3 year warranty for parts and labor
Technical Specifications
Product code 61002140AU
Connection voltage 1~ 50/60 Hz 230 V ±15 %
Fuse (delayed) 10 A
Minimum generator power 5.5 kVA
Output (MMA) 28% ED 140 A/25.6 V (28 %)
Output (MMA) 100% ED 80 A/23.2 V
Open circuit voltage 12 V
Stick electrode sizes 1.5…3.25 mm
Welding range (MMA) 10A/15V - 140A/38V
Welding range (TIG) 10A/1V - 150A/37V
Operating temperature range –20…+40 °C
External dimensions LxWxH 361 × 139 × 267 mm
Weight (no accessories) 5.4 kg
Degree of protection IP23S
Standards IEC 60974-1 IEC 60974-10 IEC 61000-3-12
Ideal for site use, you can use Minarc Evo 180 from mains or generator power supplies, even with extra long supply cables. Minarc Evo is easy to carry, so you can normally take everything you need in one journey.
Package includes earth return and welding cables (3 m) and shoulder strap.
Benefits
- Premium welding performance
- Use with all electrode types
- Use with long supply cables
- PFC technology for ultimate energy efficiency
- High current output and duty cycle
- Lightweight and portable
- Robust and durable
- Precise lift TIG technology
- Mains network or generator use
- Optional remote control
- Kemppi 3 year warranty for parts and labor
Technical Specifications
Product code 61002140AU
Connection voltage 1~ 50/60 Hz 230 V ±15 %
Fuse (delayed) 10 A
Minimum generator power 5.5 kVA
Output (MMA) 28% ED 140 A/25.6 V (28 %)
Output (MMA) 100% ED 80 A/23.2 V
Open circuit voltage 12 V
Stick electrode sizes 1.5…3.25 mm
Welding range (MMA) 10A/15V - 140A/38V
Welding range (TIG) 10A/1V - 150A/37V
Operating temperature range –20…+40 °C
External dimensions LxWxH 361 × 139 × 267 mm
Weight (no accessories) 5.4 kg
Degree of protection IP23S
Standards IEC 60974-1 IEC 60974-10 IEC 61000-3-12
| Weight (Kgs): | 8.7 |
| Minimum Sale Qty: | 1 |
| In Stock: | Yes |
Custom Field
Inner Qty 1
Cross Reference 61002140AU
Sales Unit EA
Wire Item false
Estimated Lead Time 5-8 days
Brand Kemppi
On Sale Item false
Price Always false
ns_id 7094
item_type _inventoryItem
Shipping Class NON DG
Weight (Kgs) 8.7
Minimum Sale Qty 1
In Stock Yes
