In addition to the large field of vision and crystal-clear optics, which form an actual assistance system, all members of the panoramaxx series are equipped with the latest digital electronics. The patented Shadetronic and Fadetronic technologies in combination with the 5-point sensor system and the re-charge energy concept are the core elements.
FEATURES:
- Twilight function
- Sensitivity adjustment
- True colour view
- Warranty extension 2+1Years
- New energy concept
- Delay function
- Overhead welding
SPECIFICATIONS:
- Energy supply: solar cells, Li polymer battery pack, chargeable via Micro-USB
- Battery life range: 300 to 500 charging cycles
- Sensoric: Five sensors
- Sensitivity: continuously, new with “Super High” sensitivity
- Switching time
- light to dark:
- 0.090 ms at 20°C
- 0.070 ms at 55°C
- dark to light:
- 0.1 s to 2.0 s (with FadeTronic)
- Field of vision: 2.3 to 6.3 times bigger than a 100 x 50 mm standard ADF
- Classification: EN3791/1/1/2
- Shape stability:
- Mask: up to 220°C
- Front cover lens: up to 137°C
- Eye protection: UV/IR protection: maximum protection at all shade levels
- Operating temperature: -10°C to + 55°C / 14°F to 131°F
- Storage temperature: -20°C to + 70°C / -4°F to 158°F
- Weight: 575 g
- Standards: CE, ANSI, EAC, AS/NZS, compliant with CSA Z94.3, additionally with PAPR version EN 12941 (TH3) and suppliedair version EN 14594 (3B). Compliant with pr ISO 16321 standard „WIG+“ („low amp Tig“)
APPLICATIONS:
- Elektrode Welding (Stick Welding, SMAW)
- MIG/MAG (GMAW)
- GMAW High melting rate process
- Flux Cored Wire Welding
- TIG Welding (GTAW)
- Plasma Arc Welding
- Plasma Cutting
- Gas Welding
- Grind Mode
| Minimum Sale Qty: | 1 |
