Fully automatic welding helmet (no manual adjustment necessary) with true color view, ADF with shade level range 4/5-13 with autopilot.
SPECIFICATIONS:
- Shade levels:
- inactive: Shade level 4
- active: Shade level 5-13
- Autopilot: ADF with shade level range 4/5-13 with autopilot (automatic shade level adjust-ment), +/- 2 individual manual offset
- Manual mode: Continuous external adjustment in two shade level ranges 5-9 and 9-13
- Sensitivity: Continuously adjustable, new with “Super High” sensitivity
- Grind mode: External adjustment, shade level 4
- Twilight function: Patented twilight adjustment, adjustable from 0.1 to 2.0 seconds.
- Switching time
- light to dark: 0.170 ms at room temperature 0.110 ms at 55 °C / 137 °F
- dark to light: 0.1 s - 2.0 s (with twilight function)
- Classification:
- Optical class: 1
- Scattered light: 1
- Homogeneity: 1
- Angular dependence: 1
-Power supply: Solar cells, 2 pcs batteries 3V exchangeable (CR2032)
- Operating time (batteries): Approx. 3,000 hours
- Sensors: 3 sensors, variable detection angle with movable sensor slider
- Field of view: 50 x 100 mm / 1.97 x 3.94”
- Shape stability:
- Welding mask: up to 220 °C / 428 °F
- Front cover lens: up to 137 °C / 279 °F
- Eye protection (Ultraviolet / Infrared Protection): maximum protection at any shade level
- Operating temperature: -10°C to + 70°C / 14°F to 158°F
- Storage temperature: -20°C to + 80°C / -4°F to 176°F
- Weight: 500g
- Application rangesAny electric arc welding process Electrode Welding (Stick Welding, SMAW) / MIG / MAG (GMAW) / GMAW High melting rate process / Flux Cored Wire Welding / TIG welding (GTAW) / Plasma Arc Welding / Plasmacutting &; Oxy-gas Welding
- Scope of delivery: Welding helmet, instruction manual, storage bag, batteries, warranty card and one front cover lens
-Standards: CE, ANSI, EAC, AS/NZS, complies with CSA Z94.3
