The panoramaxx quattro was developed for use in heavy metal construction, where work is often carried out with a lot of energy and in a wide variety of welding positions. Especially in constrained positions, there is no straight view of the welding point. Perfect viewing angle dependence, confirmed by the best test mark of 1 according to the EN 379 standard, guarantees that panoramaxx quattro welders always have the best view of the welding process without manual adjustment of the protection level. This results in uninterrupted and fatigue-free working and improved performance.
FEATURES:
- ShadeTronic
- FadeTronic
- Re-charge
- 5-point Detection
- Grinding mode
- Twilight function
- Sensitivity adjustment
- True colour view
- Warranty extension 2+1 years
- New energy concept
- Delay function
- Overhead welding
SPECIFICATIONS:
- Shade levels:
- ShadeTronic inactive: shade level 3.0
- active, manual: shade levels 8-13
- ShadeTronic 4-13 with individual calibration option ± 2.
- Energy supply: solar cells, Li polymer battery pack, chargeable via Micro-USB
- Battery life range: 300 to 500 charging cycles
- Sensoric: Five sensors
- Sensitivity: continuously, new with “Super High” sensitivity
- Switching time
- light to dark:
- 0.090 ms at 20°C
- 0.070 ms at 55°C
- dark to light:
- 0.1 s to 2.0 s (with FadeTronic)
- Field of vision: 2.3 to 6.3 times bigger than a 100 x 50 mm standard ADF
- Classification: EN3791/1/1/2
- Shape stability:
- Mask: up to 220°C
- Front cover lens: up to 137°C
- Eye protection: UV/IR protection: maximum protection at all shade levels
- Operating temperature: -10°C to + 55°C / 14°F to 131°F
- Storage temperature: -20°C to + 70°C / -4°F to 158°F
- Weight: 575 g
- Standards: CE, ANSI, EAC, AS/NZS, compliant with CSA Z94.3, additionally with PAPR version EN 12941 (TH3) and suppliedair version EN 14594 (3B). Compliant with pr ISO 16321 standard „WIG+“ („low amp Tig“)
APPLICATIONS:
- Elektrode Welding (Stick Welding, SMAW)
- MIG/MAG (GMAW)
- GMAW High melting rate process
- Flux Cored Wire Welding
- TIG Welding (GTAW)
- Plasma Arc Welding
- Plasma Cutting
- Gas Welding
- Grind Mode
| Inner Qty: | 1 |
