- Poly v-belt and motor driving system for longer service life
- Soft start to reduce recoil force during motor start up
- Electronic constant speed control
- Positive mitre stops for quick and easy adjustment
SPECIFICATIONS:
- Capacity - Mitre angle - 0 - 45° left & 0 - 57° right
- Capacity - Bevel angle - 0 - 45° left & right
- Capacity - Positive mitre angle stop - 0, 15, 22.5, 31.6, 45°
- Input power - 1,450W
- No load speed - 3,800 (min-1)
- Blade diameter - 262mm
- Blade bore - 25.4mm
- Weight - 19.5kg
- 525 x 1050 x 615mm
- Standard accessories - Blade, dust bag, vice assembly, and wrench
- Maximum Cutting Capacity
0° (Right angle) - 88mm x 312mm / 91mm x 300mm
Mitre right / left 45° - 88mm x 218mm / 91mm x 200mm
Mitre right 57° - 88mm x 165mm / 91mm x 150mm
Bevel left 45° - 55mm x 305mm / 60mm x 290mm
Bevel right 45° - 30mm x 305mm / 35mm x 290mm
Mitre right / left 45° + Bevel left 45° - 55mm x 218mm / 60mm x 200mm
Mitre right / left 45° + Bevel right 45° - 30mm x 218mm / 35mm x 200mm
Minimum Sale Qty: | 1 |
