FEATURES:
- Large stroke, therefore suitable for use of core drills, spiral drills and countersinks
- Magnetic base with high holding power permits working on vertical surfaces and overhead
- Robust Metabo marathon motor with internal wiring for long service life
- Integrated coolant container for easy to dose internal cooling of the core drill
- Bright LED light for easy alignment in poor light conditions
- Swarf protection can be fixed without tools and protects the user from metal shavings and tool contact
- Protective circuit starts motor only if the magnet is activated
- Restart protection: prevents unintentional start-up after power supply interruption
- Lockable slide for comfortable tool change
- Handle for easy carrying and lifting
- Resistant mains cable (5 m) with rubber shroud
SPECIFICATIONS:
Characteristics:
- Rated input power: 1000 W
- Output power: 520 W
- Max. drill-Ø with core drill: 32 mm / 1 1/4 "
- Max. drill-Ø with spiral drill: 13 mm / 1/2 "
- Maximum drilling depth: 50 mm / 2 "
- No-load speed: 700 rpm
- Revolutions at rated load: 450 rpm
- Bit retainer: Weldon shaft 19 mm (3/4")
- Weight: 11.9 kg / 26.2 lbs
- Cable length: 5 m / 16 ft
- Torque: 50 Nm // 443 in-lbs
- Max. depth of feed: 160 mm / 6 5/16 "
- Max. magnetic holding force: 12250 N
- Dimensions of the magnet base: 90 x 189 mm // 3 9/16 x 7 1/2 "
- Height carriage lowest position: 343 mm / 13 1/2 "
- Height carriage topmost position: 490 mm / 19 9/32 "
Vibration:
- Drilling in metal: 2.5 m/s²
- Uncertainty of measurement K: 1.5 m/s²
Noise emission:
- Sound pressure level: 85 dB(A)
- Sound power level (LwA): 98 dB(A)
- Uncertainty of measurement K: 3 dB(A)
SCOPE OF DELIVERY:
- Ejector pin 75 mm
- Safety strap
- Hexagon socket wrench SW 4
- Swarf protection guard
- Transport case
The machine shown may differ in equipment and technical detailsdepending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
- Large stroke, therefore suitable for use of core drills, spiral drills and countersinks
- Magnetic base with high holding power permits working on vertical surfaces and overhead
- Robust Metabo marathon motor with internal wiring for long service life
- Integrated coolant container for easy to dose internal cooling of the core drill
- Bright LED light for easy alignment in poor light conditions
- Swarf protection can be fixed without tools and protects the user from metal shavings and tool contact
- Protective circuit starts motor only if the magnet is activated
- Restart protection: prevents unintentional start-up after power supply interruption
- Lockable slide for comfortable tool change
- Handle for easy carrying and lifting
- Resistant mains cable (5 m) with rubber shroud
SPECIFICATIONS:
Characteristics:
- Rated input power: 1000 W
- Output power: 520 W
- Max. drill-Ø with core drill: 32 mm / 1 1/4 "
- Max. drill-Ø with spiral drill: 13 mm / 1/2 "
- Maximum drilling depth: 50 mm / 2 "
- No-load speed: 700 rpm
- Revolutions at rated load: 450 rpm
- Bit retainer: Weldon shaft 19 mm (3/4")
- Weight: 11.9 kg / 26.2 lbs
- Cable length: 5 m / 16 ft
- Torque: 50 Nm // 443 in-lbs
- Max. depth of feed: 160 mm / 6 5/16 "
- Max. magnetic holding force: 12250 N
- Dimensions of the magnet base: 90 x 189 mm // 3 9/16 x 7 1/2 "
- Height carriage lowest position: 343 mm / 13 1/2 "
- Height carriage topmost position: 490 mm / 19 9/32 "
Vibration:
- Drilling in metal: 2.5 m/s²
- Uncertainty of measurement K: 1.5 m/s²
Noise emission:
- Sound pressure level: 85 dB(A)
- Sound power level (LwA): 98 dB(A)
- Uncertainty of measurement K: 3 dB(A)
SCOPE OF DELIVERY:
- Ejector pin 75 mm
- Safety strap
- Hexagon socket wrench SW 4
- Swarf protection guard
- Transport case
The machine shown may differ in equipment and technical detailsdepending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
