- Powerful three-speed drill with extra high torque
- Robust mechanical gearbox with oil bath lubrication
- Robust die cast aluminium gear housing for optimum heat dissipation and durability
- Vario (V)-Electronics for working at customised speeds to suit various application materials
- Safety clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly
- For easy drilling of larger diameters and driving in of very long screws
SPECIFICATIONS:
Characteristics:
- Rated input power: 1800 W
- Output power: 1200 W
- Drill Ø steel: 32 mm // 1 1/4 "
- Drill-Ø soft wood: 70 mm // 2 3/4 "
- No-load speed: 0 - 170 / 0 - 320 / 0 - 470 rpm
- Revolutions at rated load: 110 / 190 / 280 rpm
- Gears: 3
- Maximum torque: 190 / 120 / 90 Nm // 1682 / 1062 / 797 in-lbs
- Collar diameter: 65 mm / 2 9/16 "
- Drill spindle with inside taper: MT 3
- Weight (without power cable): 7.8 kg / 17.2 lbs
- Cable length: 5 m / 16 ft
Vibration:
- Drilling in metal: 3.5 m/s²
- Uncertainty of measurement K: 1.5 m/s²
Noise emission:
- Sound pressure level: 90 dB(A)
- Sound power level (LwA): 101 dB(A)
- Uncertainty of measurement K: 3 dB(A)
SCOPE OF DELIVERY:
- Drift key
- long side handle
The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
Minimum Sale Qty: | 1 |
