FEATURES:
- Maximum flexibility when sawing thanks to rotating table and inclinable saw head on both sides
- Enormous cutting performance due to extremely powerful universal motor and large saw blade
- Speed control for extended range of application, e.g. for cutting of aluminium profiles and plastics
- Sliding function for wide work pieces.
- Easy transport thanks to ergonomically-designed handles and saw head lock
- Superb dust extraction capability thanks to a dual extraction port design aligned closely to the work piece.
- Vario-Constamatic (VC)-Full wave electronics for working at customised speeds to suit the application materials, and speeds that remain almost constant even under load
- Metabo Quick for changing saw blades without tools
- Soft start for long service life of motor and drive
- Fast and precise setting of common angles using stop points
- Sliding high rear fence profiles for safe sawing
- Material clamp for secure fixing of the work piece from the top or front
- Integrated, pull-out table width extensions made from die-cast aluminium
- Depth guide for easy creation of grooves
- All scales and operating elements are visible from the working position and can be operated intuitively
SPECIFICATIONS:
Characteristics:
- Dimensions: 950 x 765 x 660 mm // 3.2 x 2.5 x 2.2 ft
- Support surface1: 070 x 505 x 365 mm
- Maximum cutting width 90°/45°: 320 / 223 mm // 12 9/16 / 8 3/4 "
- Maximum cutting depth at 90°/45°: 120 / 76 mm // 4 11/16 / 3 "
- Cutting capacity 90°/90°: 320 x 120 mm // 12 9/16 x 4 11/16 "
- Cutting capacity 45°/45°: 223 x 76 mm // 8 25/32 x 3 "
- Turntable setting left/right: 47 / 60 °
- Saw blade tilt left/right: 46 / 46 °
- Saw blade: 315 x 30 mm // 12 3/8 x 1.181 "
- Rated input power: 1600 W
- Rated input power S1 100%: 1600 W
- Rated input power S6 20%: 2200 W
- No-load speed: 3100 - 4100 rpm
- Revolutions at rated load: 4100 rpm
- Cutting speed: 51 - 68 m/s // 167 - 223 ft/s
- Weight: 27.2 kg / 60 lbs
- Cable length: 2.1 m / 7 ft
Noise emission:
- Sound pressure level: 89 dB(A)
- Sound power level (LwA): 98 dB(A)
- Uncertainty of measurement K: 2.6 dB(A)
SCOPE OF DELIVERY:
- Carbide saw blade (84 teeth)
- 2 Table length extensions
- Material clamp
- Adapter 35/58 mm
The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
