FEATURES:
- Maximum drilling progress and high breaking performance thanks to maintenance-free brushless motor and high-performance hammer action
- Long service life thanks to brushless technology and robust aluminium die-cast housings of gear and motor
- Combination hammer with 2 functions: hammer drilling and chiselling
- Metabo VibraTech (MVT) with double dampening: Decoupled handle and impact-absorbing counter-oscillating weight actively reduce vibrations for healthy working also in continuous use.
- Ergonomically shaped, slim gripping area with large speed control trigger for comfortable working
- Easily accessible locking switch for chiselling in continuous mode
- Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
- Optional reduction of speed and impact energy for working in softer materials
- Electronic soft start for precise spot-drilling
- Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly
- Restart protection: prevents unintentional start-up after power supply interruption
- Overload protection: protects the motor from overheating
- Low-dust chiselling and drilling with external dust extraction ESA max (accessories)
SPECIFICATIONS:
Characteristics:
- Max. single blow energy (EPTA): 8.7 J
- Maximum impact rate: 2900 bpm
- Rated input power: 1150 W
- Drill-Ø concrete with hammer drills: 40 mm / 1 9/16 "
- Drill-Ø masonry with core bits: 105 mm / 4 1/8 "
- No-load speed: 350 / 500 rpm
- Revolutions at rated load: 350 / 500 rpm
- Bit retainer: SDS-max
- Collar diameter: 64.6 mm / 2 9/16 "
- Weight (without power cable): 8.3 kg / 18.3 lbs
- Cable length: 6 m / 236 7/32 "
Vibration:
- Hammer drilling concrete: 10.8 m/s²
- Uncertainty of measurement K: 1.5 m/s²
- Chiseling: 9.6 m/s²
- Uncertainty of measurementK: 1.5 m/s²
Noise emission:
- Sound pressure level: 93 dB(A)
- Sound power level (LwA): 104 dB(A)
- Uncertainty of measurement K: 3 dB(A)
SCOPE OF DELIVERY:
- rubber-coated side handle
- Drilling depth guide
- Lubricant for tool shank end
- Duster
- Plastic carry case
The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
- Maximum drilling progress and high breaking performance thanks to maintenance-free brushless motor and high-performance hammer action
- Long service life thanks to brushless technology and robust aluminium die-cast housings of gear and motor
- Combination hammer with 2 functions: hammer drilling and chiselling
- Metabo VibraTech (MVT) with double dampening: Decoupled handle and impact-absorbing counter-oscillating weight actively reduce vibrations for healthy working also in continuous use.
- Ergonomically shaped, slim gripping area with large speed control trigger for comfortable working
- Easily accessible locking switch for chiselling in continuous mode
- Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
- Optional reduction of speed and impact energy for working in softer materials
- Electronic soft start for precise spot-drilling
- Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly
- Restart protection: prevents unintentional start-up after power supply interruption
- Overload protection: protects the motor from overheating
- Low-dust chiselling and drilling with external dust extraction ESA max (accessories)
SPECIFICATIONS:
Characteristics:
- Max. single blow energy (EPTA): 8.7 J
- Maximum impact rate: 2900 bpm
- Rated input power: 1150 W
- Drill-Ø concrete with hammer drills: 40 mm / 1 9/16 "
- Drill-Ø masonry with core bits: 105 mm / 4 1/8 "
- No-load speed: 350 / 500 rpm
- Revolutions at rated load: 350 / 500 rpm
- Bit retainer: SDS-max
- Collar diameter: 64.6 mm / 2 9/16 "
- Weight (without power cable): 8.3 kg / 18.3 lbs
- Cable length: 6 m / 236 7/32 "
Vibration:
- Hammer drilling concrete: 10.8 m/s²
- Uncertainty of measurement K: 1.5 m/s²
- Chiseling: 9.6 m/s²
- Uncertainty of measurementK: 1.5 m/s²
Noise emission:
- Sound pressure level: 93 dB(A)
- Sound power level (LwA): 104 dB(A)
- Uncertainty of measurement K: 3 dB(A)
SCOPE OF DELIVERY:
- rubber-coated side handle
- Drilling depth guide
- Lubricant for tool shank end
- Duster
- Plastic carry case
The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
