FEATURES:
- Multi hammer with 4 functions: hammer drilling, drilling without impact in two speeds and chiselling
- Metabo Quick: quick change between SDS Plus hammer chuck and keyless chuck for drilling in wood and metal
- Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
- Thumbwheel for preselection of the speed and impact rate
- Two-speed gear unit: two drilling speeds for effective drilling in wood and metal
- Metabo Marathon-motor with dust protection for long service life
- High performance hammer action, precisely mounted in a housing made of aluminium alloy: long-lasting and robust
- Perfect ergonomics thanks to the centre of gravity being near the hand and optimised handle contour
- Bottom switch protected against damage and dust
- Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly
- Restart protection: prevents unintentional start-up after power supply interruption
- Lockable switch for comfortable working in continuous operation
- Cable-protecting ball joint for optimal freedom of motion when working
- With metaBOX, the intelligent solution for transport and storage
SPECIFICATIONS:
Characteristics:
- Max. single blow energy (EPTA): 3.4 J
- Maximum impact rate: 4500 bpm
- Rated input power: 1100 W
- Drill-Ø concrete with hammer drills: : 28 mm / 1 3/32 "
- Drill-Ø masonry with core bits68 mm / 2 11/16 "
- Drill Ø steel: 13 / 6 mm // 1/2 / 1/4 "
- Drill-Ø soft wood: 35 / 30 mm // 1 3/8 / 1 3/16 "
- No-load speed: 0 - 900 / 0 - 2100 rpm
- Revolutions at rated load: 900 / 2100 rpm
- Bit retainer: SDS-plus
- Collar diameter: 50 mm / 1 31/32 "
- Weight (without power cable): 3.3 kg / 7.4 lbs
- Cable length: 4 m / 13 ft
Vibration:
- Drilling in metal: 4.3 m/s²
- Uncertainty of measurement K: 1.5 m/s²
- Hammer drilling concrete1: 3.5 m/s²
- Uncertainty of measurement K: 1.5 m/s²
- Chiseling: 7.2 m/s²
- Uncertainty of measurement K: 1.5 m/s²
Noise emission:
- Sound pressure level: 90 dB(A)
- Sound power level (LwA)v9: dB(A)
- Uncertainty of measurement K: 3 dB(A)
SCOPE OF DELIVERY:
- Hammer chuck for tools with SDS-plus shank end
- Drilling depth guide
- metaBOX 145 L
- Keyless chuck for tools with cylindrical shank
- rubber-coated side handle
The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
