- Efficient brushless motor
- Powerful tightening & loosening torque
- Compact at 169mm in length
- IP56 dust & water resistant
SPECIFICATIONS:
- Capacity - Ordinary bolt - M10-M24 (3/8" to 1")
- Capacity - High-strength bolt - M10-M20 (3/8" to 3/4")
- Tightening torque*¹ - 770Nm
- Nut busting torque*² - 1,050Nm
- Tip condition - 12.7 mm (1/2”) square drive
- No-load rotation speed - 4 - 0 to 2,400 min-¹
- No-load rotation speed - 3 - 0 to 2,100 min-¹
- No-load rotation speed - 2 - 0 to 1,800 min-¹
- No-load rotation speed - 1 - 0 to 1,500 min-¹
- Impact rate - 4 - 0 to 3,400 min-¹
- Impact rate - 3 - 0 to 3,000 min-¹
- Impact rate - 2 - 0 to 2,600 min-¹
- Impact rate - 1 - 0 to 2,200 min-¹
- LED light - White LED (SW interlocked)
- Type of switch - Trigger switch with forward/reverse changeover lever (with brake)
- Weight - 1.9kg (without battery)
- Dimensions(L x H ) - 169 x 242mm
*¹: This torque is measured when tightening an M24 high-strength bolt (strength rating: 10.9) for 10 seconds with a hexagonal socket.
*²: This torque is measured when loosening an M27 high-strength bolt (strength rating :F10T) with a hexagonal socket.
Minimum Sale Qty: | 1 |
