FEATURES:
- Trigger button for taking pictures
- The IR image can be mixed with visible image
- Built-in 5000mA rechargable battery
- With USB/ WIFI data output interface
- With measuring software
- Menu in Chinese, English, Spanish, French, Japanese, Korean, Russian, Arabian
SPECIFICATIONS:
- IR image Resolution: 220x160
- IR image Measuring range: -10ºC - 450ºC
- IR image Accuracy: ±2ºC(<100ºC), 2%( ≥100ºC)
- IR image Detector: 8-14um
- IR image Frame rate: 9Hz
- IR image Field of view: Horizontal :56º,vertical:42º
- IR image Lens: Ø4mm
- IR image Measuring method: Max, Min, center spot and average
- IR image Emissivity: 0.1-1(adjustable)
- IR image Color palettes: 8 types
- IR image Resolution: 640x480
- Visible camera Frame rate: 25Hz
- Visible camera Illumination: LED
- Screen size: 3.5 inch
- Image: outline fusion, overylay fusion, picture in picture, IR image, visible
- Data output: USB/WIFI
- Image storage: 8G, can save 20,000 pictures
- Image format: TIFF
- Working temperature: -10ºC-50ºC
- Protection level: IP54
- Power supply: Rechargable battery, for 5 hours working
- Size: 230×100×90mm
- Weight: 420g
| Minimum Sale Qty: | 1 |
