SPECIFICATIONS:
- Bore diameter: 12.7 mm
- Height (H): 142.8 mm
- Length (L): 186 mm
- Width (W): 50.8 mm
- Stroke: 73 mm
- Air consumption at free speed (Normo): 5.2 1/sNl
- Air consumption at free speed: 1.9 l/s
- Air inlet thread size (in): 1/4
- Air inlet thread type: NPT
- Max dynamic air working pressure: 6.3 bar
- Min hose diam (16 ft hose length): 0.38 in
- Min hose diam (5 m hose length): 9.5 mm
- Sound Power: 108 dB(A)
- Sound Pressure: 97 dB(A)
- Uncertainty vibration-K: 2.7 m/s²
- Vibration: 12.9 m/s²
- Blow per minute: 1740
- Chisel shank diameter (in): 0.401
- Chisel shank diameter (mm): 10.2
- Energy: 4.6 J
- Max rivet size aluminium (in): 1/4
- Max rivet size aluminium (mm): 6.4
- Rivet hammer type: 4X
- Starting system: Trigger
| Inner Qty: | 1 |
