Compact MIG/MAG welder with manual, synergic (Auto), pulse (Auto Pulse) and double pulse processes. 350 A with 40% duty cycle. Intelligent setting of welding parameters with Weld Assist. LCD colour display and LED work lights for excellent handling. Incl. workpack with characteristic curves for Fe, Ss, Al, CuSi, CuAl, Fe metal, Fe rutile, FC-CrNiMo. Suitable for generators.
FEATURES:
- Color LCD display
- Work pack welding software programs incl. Fe, Ss, Al, CuSi, CuAl materials
- Weld Assist parameter setting
- WiseFusion arc performance process
- LED work lights
- 6 memory channels
- Powerlog
- Gas guard and gas regulation valve
- Wire inch and gas test buttons
- Kinetic spool brake
- Cabinet lighting
- Auto calibration
- USB port
- Safe-to-lift
- PIN lock
- Cycle timer
SPECIFICATIONS:
- Connection voltage 3~ 50/60 Hz: 380 - 460 V ± 10 %
- Fuse: 16A
- Output:
- 40% ED:350 A (MMA 330 A)
- 60% ED: 280A
- 100% ED: 220A
- Wire Feed Mechanism: 4-roll, single-motor
- Wire Feed Speed: 0.5 - 25 m/min
- Rated Power At Max Current: 14kVA
- Recommended Generator Power (min): 20kVA
- Gun Connection: Euro
- Wire Spool Max Weight: 20kg
- Wire Spool Max Diameter: 300mm
- Filler Wires:
- Ss: 0.8mm - 1.2mm
- Al: 0.8mm - 1.2mm
- Fe: 0.8mm - 1.2mm
- MC/FC: 0.8mm - 1.2mm
- Diameter of Feed Rolls: 32mm
- Welding Current and Voltage Range:
- MIG: 15 A/10 V - 350 A/ 45 V
- TIG: 15 A/1 V - 350 A/ 45 V
- MMA: 15 A/10 V - 330 A/ 45 V
- Operating Temperature Range: -20ºC - +40ºC
- Degree of Protection: IP23S
- Standards: IEC 60974-1, -10
- EMC Class: A
- Storage Temperature Range: -40ºC - +60ºC
- Shielding Gas Pressure (Max): 0.5 MPa
- Dimensions (L x W x H): 602mm x 298mm x 447 mm
- Weight: 27kg
