FEATURES:
- Black finish
- Heat treated
- Heavy duty
- Colour coded to international lifting standards
- A versatile lifting and tensioning device widely used in rigging and construction
- Can be used in any direction, (must be in a straight line). Includes a chain guide fitted, to stop the load from jumping out of the pockets on the load sprocket
- All 3G Industrial Chain Lever Block mechanisms and gears are enclosed in a robust, all steel compact shell
- All gears are fitted with industrial roller bearings
- The short arm lever and the gear ratio allows minimum effort to raise maximum load with maximum security
- The top and bottom hooks come complete with cast latches
- Top and bottom hooks are fitted with ball bearings to allow rotation under load
- Ergonomic design to ensure easy and convenient handling by hand
- Machined and heat treated gears,offering better durability and longer life cycle
- Each 3G Industrial Manual Chain Lever Block is operationally tested to its rated capacity and supplied with a test certificate, relating to its stamped identification side plate
- ID plates and rivets supplied in stainless steel to avoid dangerous sparking
SPECIFICATIONS:
- Rated Capacity (kg): 500
- Colour Code: White
- Standard Lift (m): 1.5
- Test Load (Kn): 7.3
- Headroom H (mm): 305
- Effort on lever to lift full load (N): 340
- No. of load chain falls: 1
- Diameter of load chain (mm): 5
- Length of lever handle D (mm): 288
| Inner Qty: | 1 |
