FEATURES:
- Made in Europe
- Dual motors for powerful, best-in-class suction
- High extraction performance: max suction pressure 25,000pa, max air flow 380m³/hour
- Auto or Manual On/Off controls: Auto syncs with MIG torch trigger via current sensor*
- Spark arrestor/filter shields filter from coarse/hot particles, and reduces fire risk**
- Cleanable filter for extended service life & reduced operating cost
- Unique Anti-Clog filter technology: Conical filter and upward airflow prevents debris buildup, boosting airflow and filter life
- Large dust collection bin, allows safe removal of dust ejected from filter cleaning
- PFTE-coated filter for ease of cleaning
- Full filter warning
- Individual on/off control of each motor (1 motor for standard suction power, 2 motors for maximum suction)
SPECIFICATIONS:
- Power supply: Single phase ~230V 15A
- Dimensions (mm): H1070 x W470 x L485
- Length 485mm excluding inlet tube, length 600mm including inlet tube
- Weight: 34kg
- Motor size: 2 x 1.3kw = total 2.6kw
- Max air flow: 380m³ / hour
- Max suction pressure: 25,000pa
- Filter type: M Class PTFE 99.9% 0.3μm, conical cartridge
- Filter surface area: 4m² with conical anti-clog technology
- Filter cleaning: in-situ cleaning via jet-clean funtion, remove/clean filter and dust bin for periodic maitenance
- Noise level: 72 dBA
- Max suction hose length: 20m
APPLICATIONS:
- Gas MIG welding
- Gasless and Flux-Core welding
- NOT suitable for extraction of fumes that contain; aluminium dust, oil mist, gases, or water vapour
