FEATURES:
- Auto On-Off, syncs with MIG torch trigger via current sensor
- Auto on/off is plug & play when using Weldclass FT36E MIG torch, other brand fume torches require earth clip (included)
- Cleanable filter for extended service life & reduced operating cost
- Filters must be removed for cleaning, using appropriate PPE
- Spark deflector shields filter from coarse/hot particles, and reduces fire risk**
- Carbon filter removes odours from filtered air
- Dust collection tray allows safe removal of dust ejected from filter cleaning
- PFTE-coated filter for ease of cleaning
- Variable speed (suction power) control
- Filter fullness indicator
SPECIFICATIONS:
- Power supply: Single phase ~230V 10A
- Dimensions (mm): H600 x W280 x L475
- Weight: 24kg
- Motor size: 1.2kw
- Outlets: Single outlet/torch connection
- Max air flow: 200m³ / hour
- Filter type: E12 99.9% 0.3μm PTFE 99.9% 0.3μm,cylindrical cartridge
- Filter surface area: 6m²
- Filter cleaning: Remove-to-clean filter, with dust collection bin
- Noise level: 70 dBA
- Max suction hose length: 5m
APPLICATIONS:
- Gas MIG welding
- Gasless and Flux-Core welding
- NOT suitable for extraction of fumes that contain; aluminium dust, oil mist, gases, or water vapour
| Inner Qty: | 1 |
