This durable impact wrench is able to deliver the torque you need for disassembly thanks to its reliable double rocking dog clutch mechanism. Its durability is due to the choice of high quality materials, and its ergonomics are based on a soft start trigger and low vibration level, which ensure worker and operator safety. The CP6130/CP6240 Series consists of 2 models: CP6130-T70 delivers up to 12,500 Nm and CP6240-T120 delivers up to 25,000 Nm.
SPECIFICATIONS:
- Length (L): 610 mm
- Power weight ratio: 410 Nm/kg
- Side to Center: 90 mm
- Free Speed: 3000 rpm
- Max working torque fwd: 5500 Nm
- Max torque reverse: 12400 Nm
- Min working torque fwd: 5.1 Nm
- Torque limited: No
- Air inlet thread size (in): 1
- Max dynamic air working pressure: 6.3 bar
- Min hose diam (16 ft hose length): 0.75 in
- Min hose diam (5 m hose length): 19 mm
- Sound Power: 118 dB(A)
- Sound Pressure: 107 dB(A)
- Uncertainty vibration-K: 1.5 m/s²
- Vibration (m/s²): 4.5
- Blow per minute: 800
- Body: Aluminum
- Clutch housing: Aluminum
- Clutch lubrication type: Grease
- Handle type: T-Handle
- Impact mechanism: Double rocking dog
- Output drive size (in): 2-1/2
- Output drive type: Sq
- Output retainer type: Hole
- Side handle: Yes
- Starting system: Lever
| Inner Qty: | 1 |
