The STEEL EDGE type is particularly well-suited to edge grinding and deburring work on steel and cast steel components. Its applications also include grinding of chamfers in preparation for weld seams and grinding of contours. Series A mounted points are generally used on larger components. Due to the special shapes, it is possible to grind in a variety of contours. The applications range from grinding out slits and grooves in hard-to-reach areas to machining bores and small holes as well as smoothing.
FEATURES:
- Long tool life and low tool wear due to hard, dimensionally stable bond.
- Economical to use due to the high edge stability even on low-speed tool drives.
- Particularly well suited to work on edges.
SPECIFICATIONS:
- Dia. external: 17 mm
- Dia. shank: 6 mm
- Grit size: 30
- Length, shank: 40
- Max. RPM: 54500 RPM
- RPM, optimum: 40000 RPM
- Shape: A 14
- Width: 22 mm
- Packaging unit: 10 pieces
RECOMMENDATIONS FOR USE:
- STEEL EDGE mounted points perform best at a cutting speed of 25 to 40 m/s.
APPLICATIONS:
- Deburring
- Finishing
- Grinding out
- Grouting
- Leveling
- Surface work
- Working on edges (chamfering, rounding)
- Work on weld seams
MATERIALS THAT CAN BE WORKED:
- Cast steel
- Steel
